Flow Meter ALIA Electromagnetic Type AMF100 Series

Type AMF100 Series

SPECIFICATION
Size: Cable Entry:
150 , 200 , 250 , 300 , 350 , 400 , 450 Standard:  PG11  Option:1/2″NPTF
500 , 600 , 700 ….. 6000 mm Grounding Resistance:
Measuring Range: Must be  less than 10
Velocity   0-0.25 m/s min. Accuracy:
                0-12 m/s max. +/-2% of reading (Velocity >=0.5 m/s)
Material: +/-0.8% of Full Scale (F.S.>2 m/s)
Protection tube +/-0.01 m/s (Velocity < 0.5 m/s)
Stainless Steel 316 Repeatability:
Screw +/-0.4% of reading
Stainless Steel 316 Process Temperature:
Electrode
-10 ~ 80 oC
Stainless Steel 316L  Ambient Temperature:
Cap
-25 to +70 oC
PTFE Max. Pressure:
Ball Valve 10 Kg/cm2
Stainless Steel 316(Optional) Conductivity:
Hot-Tap tool / Kit More than 10 uS/cm
Stainless Steel 304(Optional) Weight:
Mounting: 3 ~ 10 Kg
Compact or separate Coil Resistance:
Process Connection: 70 – 98
Threaded Sensor Diameter:
Threaded, 2″ BSP Female 45 mm
Flange Sensor Length:
Flange, JIS / ANSI / DIN 310mm (for 150 ~ 600mm pipe ID)
Installation: 550mm(for 600 ~ 2400mm pipe ID)
Direct insert to the pipe 800mm(for 2400 ~ 4200mm pipe ID)
Insert with Ball Value 1050mm (for 4200 ~ 6000mm pipe ID)
Hot-Tap into pressurised pipe
Protection Class:
IP 67
IP 68 (Submersible)
Explosion Proof:
Exd(ib)ibqIIBT5

(with AMC3200 only)
Download Katalog : AMF100.pdf



Category: Tags: , , , , , ,

Description

Jual Flow Meter ALIA Electromagnetic Type AMF100 Series, Harga Flow Meter ALIA Electromagnetic Type AMF100 Series, DistributorFlow Meter ALIA Electromagnetic Type AMF100 Series, supply Flow Meter ALIA Electromagnetic Type AMF100 Series, jual berbagai macam ukuran Flow Meter ALIA Electromagnetic Type AMF100 Series, Kami menjual berbgai macam, merk, type size Flow Meter ALIA Electromagnetic Type AMF100 Series
