Spesifikasi :
Number of Inputs:
Display:
3 Channels
3.5" Mono-screen LCD with Backlit
Flow Function:
Response Time:
Input
100 ms
4-20 mA / Frequency (0-10 KHz)
Keypad:
Display
6 keys for programming and display
5 digits flowrate with decimal point
control
13 digits totalizer with decimal point
Engineer Unit:
Accuracy
21 different engineering units
+/-0.1% of reading
Parameter Protection:
Temperature Function:
2 Password entries (6 Digits) for
one or two point (Energy calculator)
Supplier and User
Input:
Logging Rate:
PT100 / 4-20 mA
1 minutes ~ 60 minutes Per Data
Display
Recording Capability:
4 digits temperature value with decimal point
30 days (1 Data/minutes)
Accuracy
1800 days (1 Data/Hour)
+/-0.1 oC
Storage Memory:
Pressure Function:
8 MB (on board)
Input
Recycling Mode:
4-20 mA
Newest data overwrites oldest data
Display
Protection Class:
5 digits pressure value with decimal point
NEMA4 / IP65 (Fascia sealing)
Accuracy
Weight:
+/-0.1% of reading
0.5 Kg Maximum
Calculation Function:
Dimensions:
Ideal Gas, Temperature & Pressure Comp.
96mm (W) * 96 mm (H) *150 mm (D)
General Gases, Temp & Pressure Comp.
Ambient Temperature:
Natural Gas, NX-192 Formula
-10 ~ +60 oC
Saturated Steam, Superheated Steam
Ambient Humidity:
Liquid Mass, Density calculation
10% ~ 85%RH (5 ~ 40 oC)
Alarm Types:
Power Supply:
High & Low alarm, Incr. & Decr. alarm
85-260VAC, 50/60Hz
Aux. Power Output:
Vibration Test:
12VDC / 24VDC,100mA for Flow Transmitter
10~60Hz ,10 m/S2 for 3 hours
24VDC, 100mA for Temperature Transmitter
Power Consumption:
24VDC ,100mA for Pressure Transmitter
<=10 W
Output:
Communication:
4-20 mA, Load 750 * 1 point
RS485 (MODBUS Protocol)
Relay, 3A/250V * 1 point
Parameter Storage:
Operation parameters are stored by
EEPROM for more than 10 years
Download Katalog : AFC365.pdf
